5045S Bad Boy Tractor With Loader BB5045S 48HP 4 Cylinder Diesel

5045 Compact Tractor – Specifications & Performance Overview

The 5045 Compact Tractor is built for serious property maintenance, farming, landscaping, and commercial applications where power, durability, and versatility matter most. Designed with a heavy-duty frame, powerful diesel engine, advanced hydraulic system, and available synchro or hydrostatic transmission options, the 5045 delivers the performance needed to handle demanding jobs with confidence.

Whether you are moving materials, operating implements, maintaining large properties, or tackling loader work, the 5045 is engineered to provide dependable performance day after day.

Engine & Power

At the heart of the 5045 is a robust 48 HP, 4-cylinder, water-cooled diesel engine designed for excellent torque, fuel efficiency, and long-term durability. With 139.5 cubic inches of displacement and an 11.8-gallon fuel tank, the 5045 is built for long workdays and heavy workloads.

The emissions system utilizes DPF and DOC technology for clean, efficient operation while maintaining strong engine performance.

Engine highlights include:

• 48 HP diesel engine
• 4-cylinder water-cooled design
• 139.5 cubic inch displacement
• 11.8-gallon fuel capacity
• Rated engine speed: 2,600 RPM
• 38.4 PTO horsepower

Synchro Models (5045S / 5045CS)

• 16 forward / 16 reverse gears
• Excellent for field work and consistent pulling applications

Hydraulic Performance

The advanced hydraulic system provides exceptional responsiveness and lifting capability for implements and loader attachments.

Hydraulic features include:

• Up to 16.4 GPM total hydraulic flow
• Dedicated 5 GPM steering pump
• Category 1 three-point hitch
• 3,306 lb hitch lift capacity
• 2,425 lb lift capacity at 24 inches behind link ends

The 5045 is ready to power a wide range of implements including rotary cutters, tillers, box blades, grapples, augers, and more.

PTO Performance

Dual-speed PTO capability provides flexibility and efficiency when operating PTO-driven implements.

• 540 / 540E PTO options
• PTO speeds: 584 / 791 RPM

The economical PTO mode allows operators to maintain implement performance while reducing engine RPM and fuel consumption during lighter-duty applications.

Dimensions & Stability

The 5045 offers a larger, heavier platform for improved traction, stability, and lifting performance while maintaining excellent maneuverability.

Key dimensions include:

• Overall length: 127.4 inches
• Overall width: 64.9 inches
• Wheelbase: 71.1 inches
• Ground clearance: 15.5 inches

Operating weights:

• 5045S/H Models: 3,831 lbs

Front Loader – Model BBL500

The available BBL500 front loader transforms the 5045 into a highly capable material-handling machine for dirt work, loading, grading, feed handling, and general property maintenance.

Loader specifications include:

• 72″ standard bucket
• 106.6″ maximum lift height
• 2,700 lb lift capacity at pivot pin
• 3,660 lb breakout force
• 3.1″ dig depth
• 1,075 lb shipping weight

Built for Versatility

From agricultural work and construction projects to landscaping and property management, the 5045 Compact Tractor delivers the power, hydraulic capability, and reliability needed to handle demanding tasks with ease.

With strong loader performance, advanced transmission options, high lifting capacity, and a durable diesel platform, the 5045 is built to work hard and keep productivity high in every season.
